Communication
4.2 Communication services
S7-400 Automation System, CPU Specifications
4-16 Manual, 10/2006, 6ES7498-8AA04-8BA0
Routing: Example of a TeleService application
The following figure shows the example of an application for remote maintenance of an
S7 station using a PG. The connection to other subnets is here established via modem
connection.
The lower section of the figure shows how this can be configured in STEP 7.
3*
3*
'3PDVWHU '3VODYH
0RGHP
6XEQHW
HJ03,
6XEQHW
HJ352),%86'3
6XEQHW
HJ03,
6XEQHW
HJ352),%86'3
7HOH6HUYLFH
$GDSWHU
'3PDVWHU
'3VODYH
0RGHP
&RQILJXUDWLRQLQ67(3
5HDOFRQILJXUDWLRQ
Figure 4-3 Routing: Example of a TeleService application
