6 Wiring 02.05
© Siemens AG 1998 All Rights Reserved
6-12 FM-STEPDRIVE/SIMOSTEP (FB)
6.6 Accessories
Accessories Order number
Ordering
information
Mains filter for one axis with single-phase power
supply
for 115 V = B84142-B8-R
for 230 V = B84113-C-B60
SIEMENS
component service
catalogue
Mains filter for several axes:
For single-phase mains connection for 2 axes
For single-phase mains connection for 3 axes
For three-phase mains connection with neutral
For three-phase mains connector without
neutral
for 115 V = B84142-B16-R
for 230 V = B84142-B16-R
for 115 V = B84299-K55
for 230 V = B84299-K53
for 230 V = B84143-B8-R
Motor cable (non-terminated):
Length 10 m
Length 20 m
Length 50 m
6FX5008-5AA00-1BA0
6FX5008-5AA00-1CA0
6FX5008-5AA00-1FA0
Cable for pulse interface:
For FM-353 (terminated, max. length 35 m)
For FM-NC/FM357 (FM-STEPDRIVE end
non-terminated, max. length 35 m)
6FX2002-3AC02-1xx0
6FX2002-3AD02-1xx0
SIEMENS
automation
systems catalogue:
NC60.1 or ST70, or
for NCZ
accessories
External back-up fuse:
e.g. line circuit breaker
16 A with C characteristic
32 A with C characteristic
5SX2 116-7
5SX2 132-7
SIEMENS
catalogue
of circuit breaker
and fuse systems
