Optional Configurations
5-17
High Speed Counter Encoder Module User Manual
NOTE:
Select two input jumpers from the following list. Select one jumper to
clock the counter and one jumper (or none) to gate the counter
.
The holding position simply stores the jumper until needed.
The 1
s jumper selects a 1
s internal signal to clock the counter; the gate
position is not applicable for this jumper
.
Input A jumper connects this signal to clock or gate/trigger the 16-bit
counter.
Input B jumper connects this signal to clock or gate/trigger the 16-bit
counter.
The C (for counters 2 and 5) or D (for counters 3 and 6) Input jumper allows
you to select this input to clock or gate the counter
. Clock is the default
position.
Y
ou can jumper the output from counter 3 into counter 2 to either clock or
gate the counter
.
Y
ou can jumper the output from counter 2 into counter 3 to either clock or
gate the counter
.
Y
ou can jumper the output from counter 6 into counter 5 to either clock or
gate the counter
.
Y
ou can jumper the output from counter 5 into counter 6 to either clock or
gate the counter
.
Holding Position
1
s Jumper
Input A Jumper
Input B Jumper
C/D Input Jumper
Counter 3/2/6/5
Output Jumper
To Next Page
