Siemens SIMATIC Operating Instructions

Fail-Safe Electronic Modules
8.1 8 /16 F-DI DC24V PROFIsafe Digital Electronic Module
ET 200pro Distributed I/O System - Fail-Safe Modules
86 Operating Instructions, 05/2007, A5E00394073-02
Technical Specifications
Minimum sensor signal duration See "Minimum Duration of Sensor Signals for
Proper Detection by F-DI Module" table in
"Wiring"
Protection against Overvoltage
Protection of supply voltage L+ from surge in
accordance with IEC 61000-4-5 with external
protection elements only
• Symmetrical (L+ to M)
+ 1 kV; 1.2/50 μs
• Asymmetrical (L+ to PE, M to PE)
+ 2 kV; 1.2/50 μs
Protection of inputs and outputs from surge in
accordance with IEC 61000-4-5 with external
protection elements only
Not required since cable length is < 30 m
Protection of supply voltage 1L+ from
overvoltages
Internal fuse tripped
*: Identification sets are described in the "ET200 pro Distributed I/O System" manual.
**: For requirements for sensors and actuators, see " Requirements for Sensors and Actuators "
