1FT5
08.95
1FT5/2-2
Siemens AG 1997 All Rights reserved 6SN1197–0AA20
SIMODRIVE 611 (PJ)
Plain text information
Code
Degree of protection IP 67 (not for force–ventilated motors)
IP 68 (not for force–ventilated motors)
K93
M24
Second rating plate (standard for core types) K31
Connector outlet direction
1)
Cable enters from the drive end K83
Rotated through 90° Cable enters from the non–drive end K84
Connector outlet direction
1)
rotated through 180° K85
Radial shaft sealing ring acc. to DIN 3760 K18
Shaft end: Smooth shaft K42
Vibration severity (ISO 2373)
Stage R (reduced) 600 to 1800 RPM v0.71 mm/s
>1800 to 3600 RPM v1.12 mm/s
K01
Shaft– and flange accuracy, tolerance R acc. to DIN 42955 K04
Motor with mounted pulse encoder
5000 pulses/revolution
2500 pulses/revolution
2000 pulses/revolution
1000 pulses/revolution
H28
H27
H26
H22
Motor is prepared for mounting a pulse encoder with synchronous flange
and the following absolute value encoder
2)
:
S ROC 424 Heidenhain company
S CE 65/04–418–031 T&R company
S CR 58 TWK company
S AG 661–21–26 Stegmann company
S 6FX2 ... (Siemens)
G51
Motor with integrated ROD 320 pulse encoder
3)6)
5000 pulses/revolution
2500 pulses/revolution
2000 pulses/revolution
1250 pulses/revolution
H04
G44
G42
H01
Holding brake (integrated) G45
Motor with mounted planetary gearbox VVV
Mounted working brake
4)
C00
Retrofit set prepared for encoder mounting (G51) with mounting instructions
5)
EWN:
519.4033803:1FT5042 to 1FT5046
519.4033801:1FT5062 to 1FT5066
519.4033802:1FT5072 to 1FT5108
1) Standard version corresponding to the dimension drawings Chapter 4)
2) For 1FT503V, 1FT504V only on request; not for force–ventilated motors
3) For 1FT503V, 1FT504V not possible; not for forced ventilation
4) For 1FT503V, 1FT504V and 1FT506V not possible
5) Only a maximum of 2 per motor version can be supplied ex–factory
6) Limiting frequency: 250 kHz; motors may only be designed for a winding temperature rise DT=60 K .
Cannot be combined with a connector transition direction, axial NDE.
Supplementary data
for standard
versions and
options
1FT5 AC servomotors
2 Order desi
nations 01.98
