1FT5
08.95
1FT5/3-36
Siemens AG 1997 All Rights reserved 6SN1197–0AA20
SIMODRIVE 611 (PJ)
3.2 Cantilever/axial force diagrams
Definition, refer to Chapter 2.1 General information on AC servomotors AL S.
F
A
AS
is the absolute permissible force without taking into account the bearing
alignment force, the rotor weight, the mounting position as well as force direc-
tion.
!
Caution
Axial forces are not permissible for motors with integrated holsing brake!
Definition, refer to Chapter 2.1, General information on AC servomotors AL S.
Cantilever force
Axial force
1FT5 AC servomotors
3.2 Cantilever/axial force dia
rams
