7
02.98
1-74
Siemens AG 1998 All Rights reserved 6SN1197–0AA00 02.98 Edition
SIMODRIVE 611 (PJ)
Table 7-1 (continued)
Parameter Setting elementsValue range
Instantaneous controller/pulse inhibit
via terminal 65
Delay after speed controller moni-
toring time expired ↔ instanta-
neous
R13
Selection:
int. supplementary setpoint 1
through terminal 22
Selection:
int. supplementary setpoint 2
through terminal 23
10V...+10V
10V...+10V
R16, R17, R18=setpoint
R19, R21, R22=setpoint
Ready/fault signal at termi-
nals 672/673/674
R33
Smoothing:
Speed setpoint
Speed actual value
Speed controller
Current setpoint
T = C4 ⋅ 10 kΩ
T = C5 ⋅ 5 kΩ
T = C3 ⋅ 68 kΩ
T = C6 ⋅ 1 kΩ
C4
C5
C3
C6
7.1.1 Function overview and settings using the parameter board
