Commissioning instructions for SIMOTICS M-1PH8 Premium Performance
24 Commissioning Manual, 10/2014, 610.40106.40
Additional parameterization
Booksize Combi 18 A with 300% overload/Booksize 30 A
400 V
480 V
Motor type selection
p300
1
1
Line resistance
p352
0.12
0.12
Current controller adaptation, starting point
KP
p391 8 8
Current controller adaptation, starting point
KP adapted
p392 10 10
Current controller adaptation, P gain adapta-
tion
p393 60 60
Current limit
p640
54
50
Maximum rotation speed
p1082
24,000
24,000
Torque limit, upper/motoring
p1520
19
19
Torque limit, lower/regenerative
p1521
-19
-19
Power limit, motoring
p1530
17.9
19.9
Power limit, regenerative
p1531
-17.9
-19.9
Maximum field-generating current
p1603
0
0
Pulse frequency setpoint
p1800
4
4
Modulator configuration
p1810
&H800
&H800
Current controller P gain
p1715
3
3
Reference speed reference frequency
p2000
24,000
24,000
Reference current p2002 54 50
Reference torque
p2003
19
19
Hysteresis speed n_act > n_max
p2162
480
480
