Siemens SIMOTICS M-1PH8 Commissioning Instructions

Converter data sheets and characteristics
4.2 Water cooling
Commissioning instructions for SIMOTICS M-1PH8 Premium Performance
Commissioning Manual, 10/2014, 610.40106.40
53
4.2
Water cooling
4.2.1
1PH8081-1_U2 (fp = 4 kHz)
1PH8081-1_U2, operation on Booksize 45 A
Motor/DRIVE CLiQ data
Booksize 45 A
400 V
480 V
Rated motor voltage
p304
246
246
Rated motor voltage
p305
25.0
25.0
Rated motor power p307 7.5 7.5
Rated motor power factor
p308
0.79
0.79
Rated motor frequency
p310
304.6
304.6
Rated motor speed
p311
9,000
9,000
Motor rated magnetizing current/short-circuit
current
p320 8.2 8.2
Maximum motor speed
p322
24,000
24,000
Motor stall torque correction factor
p326
90
90
Type of motor cooling
p335
2
2
Motor moment of inertia
p341
0.0045
0.0045
Motor weight (for thermal motor type)
p344
27
27
Speed at the start of field weakening Vdc =
600 V
p348 13,000 13,000
Motor stator resistance, cold
p350
0.149
0.149
Cold motor rotor resistance/damper re-
sistance d-axis
p354 0.105 0.105
Motor stator leakage inductance
p356
0.385
0.385
Motor rotor leakage inductance/damping
inductance d axis
p358 0.826 0.826
Motor magnetizing inductance/magnetizing
inductance d axis, saturated
p360 8.624 8.624
Mot_temp_mod 2/KTY warning threshold
p604
150
150
Mot_temp_mod 1/2 threshold p605 170 170
