4.2 Water cooling
Commissioning instructions for SIMOTICS M-1PH8 Premium Performance
Commissioning Manual, 10/2014, 610.40106.40
65
4.2.6
1PH8083-1_U2 (fp = 4 kHz)
1PH8083-1_U2, operation on Booksize 60 A
Motor/DRIVE CLiQ data
Booksize 60 A
400 V
480 V
Rated motor voltage
p304
320
320
Rated motor voltage
p305
26.4
26.4
Rated motor power p307 10.0 10.0
Rated motor power factor
p308
0.76
0.76
Rated motor frequency
p310
176.1
176.1
Rated motor speed
p311
5,200
5,200
Motor rated magnetizing current/short-circuit
current
p320 11.0 11.0
Maximum motor speed
p322
24,000
24,000
Motor stall torque correction factor
p326
58
58
Type of motor cooling
p335
2
2
Motor moment of inertia
p341
0.0069
0.0069
Motor weight (for thermal motor type)
p344
34
34
Speed at the start of field weakening Vdc =
600 V
p348 6,200 6,200
Motor stator resistance, cold
p350
0.1895
0.1895
Cold motor rotor resistance/damper re-
sistance d-axis
p354 0.133 0.133
Motor stator leakage inductance
p356
0.565
0.565
Motor rotor leakage inductance/damping
inductance d axis
p358 0.914 0.914
Motor magnetizing inductance/magnetizing
inductance d axis, saturated
p360 14.444 14.444
Mot_temp_mod 2/KTY warning threshold
p604
150
150
Mot_temp_mod 1/2 threshold p605 170 170
