Page #55 background imageLoading...
Page #55 background image
Converter data sheets and characteristics
4.2 Water cooling
Commissioning instructions for SIMOTICS M-1PH8 Premium Performance
Commissioning Manual, 10/2014, 610.40106.40
55
4.2.2
1PH8081-1_T2 (fp = 4 kHz)
1PH8081-1_T2, operation on Booksize 45 A
Motor/DRIVE CLiQ data
Booksize 45 A
400 V
480 V
Rated motor voltage
p304
278
278
Rated motor voltage
p305
25.6
25.6
Rated motor power p307 8 8
Rated motor power factor
p308
0.7
0.7
Rated motor frequency
p310
303.1
303.1
Rated motor speed
p311
9,000
9,000
Motor rated magnetizing current/short-circuit
current
p320 12.8 12.8
Maximum motor speed
p322
24,000
24,000
Motor stall torque correction factor
p326
90
90
Type of motor cooling
p335
2
2
Motor moment of inertia
p341
0.0045
0.0045
Motor weight (for thermal motor type)
p344
26.6
26.6
Speed at the start of field weakening Vdc =
600 V
p348 12,000 12,000
Motor stator resistance, cold
p350
0.123
0.123
Cold motor rotor resistance/damper re-
sistance d-axis
p354 0.081 0.081
Motor stator leakage inductance
p356
0.3
0.3
Motor rotor leakage inductance/damping
inductance d axis
p358 0.68 0.68
Motor magnetizing inductance/magnetizing
inductance d axis, saturated
p360 6.46406 6.46406
Mot_temp_mod 2/KTY warning threshold
p604
150
150
Mot_temp_mod 1/2 threshold p605 170 170
