Siemens SIMOTICS M-1PH8 Commissioning Instructions

Converter data sheets and characteristics
4.1 Forced ventilation
Commissioning instructions for SIMOTICS M-1PH8 Premium Performance
Commissioning Manual, 10/2014, 610.40106.40
45
4.1.5
1PH8083-1_W0_1 (fp = 8 kHz)
1PH8083-1_W0/1, operation on Booksize 60 A
Motor/DRIVE CLiQ data
Booksize 60 A
400 V
480 V
Rated motor voltage
p304
306
306
Rated motor voltage
p305
15.2
15.2
Rated motor power p307 4.5 4.5
Rated motor power factor
p308
0.66
0.66
Rated motor frequency
p310
176.8
176.8
Rated motor speed
p311
5,200
5,200
Motor rated magnetizing current/short-circuit
current
p320 10.4 10.4
Maximum motor speed
p322
24,000
24,000
Motor stall torque correction factor
p326
45
45
Type of motor cooling
p335
1
1
Motor moment of inertia
p341
0.0069
0.0069
Motor weight (for thermal motor type)
p344
29.5
29.5
Speed at the start of field weakening Vdc =
600 V
p348 6,649 6,649
Motor stator resistance, cold
p350
0.188
0.188
Cold motor rotor resistance/damper re-
sistance d-axis
p354 0.138 0.138
Motor stator leakage inductance
p356
0.337
0.337
Motor rotor leakage inductance/damping
inductance d axis
p358 0.792 0.792
Motor magnetizing inductance/magnetizing
inductance d axis, saturated
p360 14.200 14.200
Mot_temp_mod 2/KTY warning threshold
p604
150
150
Mot_temp_mod 1/2 threshold p605 170 170
