Converter data sheets and characteristics
4.1 Forced ventilation
Commissioning instructions for SIMOTICS M-1PH8 Premium Performance
Commissioning Manual, 10/2014, 610.40106.40
35
4.1.3
1PH8081-1_W0_1 (fp = 8 kHz)
1PH8081-1_W0/1, operation on Booksize 30 A
Motor/DRIVE CLiQ data
Booksize 30 A
400 V
480 V
Rated motor voltage
p304
264
264
Rated motor voltage
p305
12.2
12.2
Rated motor power p307 2.8 2.8
Rated motor power factor
p308
0.61
0.61
Rated motor frequency
p310
302.7
302.7
Rated motor speed
p311
9,000
9,000
Motor rated magnetizing current/short-circuit
current
p320 8.3 8.3
Maximum motor speed
p322
24,000
24,000
Motor stall torque correction factor
p326
78
78
Type of motor cooling
p335
1
1
Motor moment of inertia
p341
0.0045
0.0045
Motor weight (for thermal motor type)
p344
24
24
Speed at the start of field weakening Vdc =
600 V
p348 12,950 12,950
Motor stator resistance, cold
p350
0.149
0.149
Cold motor rotor resistance/damper re-
sistance d-axis
p354 0.095 0.095
Motor stator leakage inductance
p356
0.325
0.325
Motor rotor leakage inductance/damping
inductance d axis
p358 0.816 0.816
Motor magnetizing inductance/magnetizing
inductance d axis, saturated
p360 9.000 9.000
Mot_temp_mod 2/KTY warning threshold
p604
150
150
Mot_temp_mod 1/2 threshold p605 170 170
