Siemens SIMOTICS M-1PH8 Commissioning Instructions

Converter data sheets and characteristics
4.2 Water cooling
Commissioning instructions for SIMOTICS M-1PH8 Premium Performance
Commissioning Manual, 10/2014, 610.40106.40
67
4.2.7
1PH8087-1_U2 (fp = 4 kHz)
1PH8087-1_U2, operation on Booksize 45 A SLM
Motor/DRIVE CLiQ data
Booksize 45 A ALM
400 V
480 V
Rated motor voltage
p304
354
354
Rated motor voltage
p305
25.1
25.1
Rated motor power p307 11.0 11.0
Rated motor power factor
p308
0.762
0.762
Rated motor frequency
p310
169.0
169.0
Rated motor speed
p311
5,000
5,000
Motor rated magnetizing current/short-circuit
current
p320 12.4 12.4
Maximum motor speed
p322
24,000
24,000
Motor stall torque correction factor
p326
55
55
Type of motor cooling
p335
2
2
Motor moment of inertia
p341
0.0094
0.0094
Motor weight (for thermal motor type)
p344
41
41
Speed at the start of field weakening Vdc =
600 V
p348
Motor stator resistance, cold
p350
0.178
0.178
Cold motor rotor resistance/damper re-
sistance d-axis
p354 0.138 0.138
Motor stator leakage inductance
p356
0.619
0.619
Motor rotor leakage inductance/damping
inductance d axis
p358 1.001 1.001
Motor magnetizing inductance/magnetizing
inductance d axis, saturated
p360 15.248 15.248
Mot_temp_mod 2/KTY warning threshold
p604
150
150
Mot_temp_mod 1/2 threshold p605 170 170
