Converter data sheets and characteristics
4.2 Water cooling
Commissioning instructions for SIMOTICS M-1PH8 Premium Performance
Commissioning Manual, 10/2014, 610.40106.40
61
4.2.5
1PH8083-1_T2 (fp = 4 kHz)
1PH8083-1_T2, operation on Booksize 45 A
Motor/DRIVE CLiQ data
Booksize 45 A
400 V
480 V
Rated motor voltage
p304
336
336
Rated motor voltage
p305
24.0
24.0
Rated motor power p307 9.0 9.0
Rated motor power factor
p308
0.79
0.79
Rated motor frequency
p310
402.9
402.9
Rated motor speed
p311
12,000
12,000
Motor rated magnetizing current/short-circuit
current
p320 11.2 11.2
Maximum motor speed
p322
24,000
24,000
Motor stall torque correction factor
p326
60
60
Type of motor cooling
p335
2
2
Motor moment of inertia
p341
0.0069
0.0069
Motor weight (for thermal motor type)
p344
34
34
Speed at the start of field weakening Vdc =
600 V
p348
Motor stator resistance, cold
p350
0.089
0.089
Cold motor rotor resistance/damper re-
sistance d-axis
p354 0.067 0.067
Motor stator leakage inductance
p356
0.261
0.261
Motor rotor leakage inductance/damping
inductance d axis
p358 0.442 0.442
Motor magnetizing inductance/magnetizing
inductance d axis, saturated
p360 6.580 6.580
Mot_temp_mod 2/KTY warning threshold
p604
150
150
Mot_temp_mod 1/2 threshold p605 170 170
