Converter data sheets and characteristics
4.1 Forced ventilation
Commissioning instructions for SIMOTICS M-1PH8 Premium Performance
Commissioning Manual, 10/2014, 610.40106.40
41
4.1.4
1PH8083-1_V0_1 (fp = 8 kHz)
1PH8083-1_V0/1, operation on Booksize 60 A
Motor/DRIVE CLiQ data
Booksize 60 A
400 V
480 V
Rated motor voltage
p304
300
300
Rated motor voltage
p305
15.2
15.2
Rated motor power p307 4.5 4.5
Rated motor power factor
p308
0.62
0.62
Rated motor frequency
p310
401.4
401.4
Rated motor speed
p311
12,000
12,000
Motor rated magnetizing current/short-circuit
current
p320 10.5 10.5
Maximum motor speed
p322
24,000
24,000
Motor stall torque correction factor
p326
80
80
Type of motor cooling
p335
1
1
Motor moment of inertia
p341
0.0069
0.0069
Motor weight (for thermal motor type)
p344
29.5
29.5
Speed at the start of field weakening Vdc =
600 V
p348 14,671 14,671
Motor stator resistance, cold
p350
0.0893
0.0893
Cold motor rotor resistance/damper re-
sistance d-axis
p354 0.066 0.066
Motor stator leakage inductance
p356
0.190
0.190
Motor rotor leakage inductance/damping
inductance d axis
p358 0.498 0.498
Motor magnetizing inductance/magnetizing
inductance d axis, saturated
p360 6.500 6.500
Mot_temp_mod 2/KTY warning threshold
p604
150
150
Mot_temp_mod 1/2 threshold p605 170 170
