Converter data sheets and characteristics
4.1 Forced ventilation
Commissioning instructions for SIMOTICS M-1PH8 Premium Performance
Commissioning Manual, 10/2014, 610.40106.40
33
1PH8081-1_V0_1, operation on Booksize Combi with 300% overload
Motor/DRIVE CLiQ data
Booksize Combi with 300% overload
400 V
480 V
Rated motor voltage
p304
279
279
Rated motor voltage
p305
15.5
15.5
Rated motor power p307 3.5 3.5
Rated motor power factor
p308
0.5
0.5
Rated motor frequency p310 301.4 301.4
Rated motor speed
p311
9,000
9,000
Motor rated magnetizing current/short-circuit
current
p320 12.4 12.4
Maximum motor speed
p322
24,000
24,000
Motor stall torque correction factor
p326
100
100
Type of motor cooling
p335
1
1
Motor moment of inertia
p341
0.0045
0.0045
Motor weight (for thermal motor type)
p344
24
24
Speed at the start of field weakening Vdc =
600 V
p348
Motor stator resistance, cold
p350
0.119
0.119
Cold motor rotor resistance/damper re-
sistance d-axis
p354 0.082 0.082
Motor stator leakage inductance
p356
0.430
0.430
Motor rotor leakage inductance/damping
inductance d axis
p358 1.000 1.000
Motor magnetizing inductance/magnetizing
inductance d axis, saturated
p360 6.610 6.610
Mot_temp_mod 2/KTY warning threshold
p604
150
150
Mot_temp_mod 1/2 threshold p605 170 170
