Siemens SIMOTICS S-1FL6 Getting Started

Getting Started
110 A5E36037886-003, 04/2017
Par. No.
Name
Unit
Data type
r29018[0...
1]
OA version
-
Float
Description: Displays the OA version.
Index:
• [0]: Firmware version
•
[1]: Build increment number
r29400
Internal control signal status indicating
-
U32
Description:
Control signal status identifiers
Bit 0 SON, Bit 1 RESET, Bit 2 CWL, Bit 3 CCWL, Bit 4 G-CHANGE, Bit 5 P-TRG, Bit 6 CLR, Bit 7 EGEAR1,
Bit 8 EGEAR2, Bit 9 TLIM1, Bit 10 TLIM2, Bit 11 CWE, Bit 12 CCWE, Bit 13 ZSCLAMP, Bit 14 SPD1, Bit 15
SPD2, Bit 16 SPD3, Bit 17 TSET, Bit 18 SLIM1, Bit 19 SLIM2, Bit 20 POS1, Bit 21 POS2, Bit 22 POS3, Bit 23
REF, Bit 24 SREF, Bit 25 STEPF, Bit 26 STEPB, Bit 27 STEPH, Bit 28 EMGS, Bit 29 C-MODE
r29942
DO signals status indicating
-
U32
Description:
Indicates the status of DO signals.
• Bit 0: RDY
• Bit 1: FAULT
• Bit 2: INP
• Bit 3: ZSP
• Bit 4: SPDR
• Bit 5: TLR
• Bit 6: SPLR
• Bit 7: MBR
• Bit 8: OLL
• Bit 9: WARNING1
• Bit 10: WARNING2
• Bit 11: REFOK
• Bit 12: CM_STA
• Bit 13: RDY_ON
• Bit 14: STO_EP
r29979
Index of actual electronic gear
-
U32
Description:
Displays the status of position loop.
•
Bit 0 to Bit 1: Actual EGear index
