Siemens SIMOTICS S-1FL6 Getting Started

Getting Started
52 A5E36037886-003, 04/2017
Digital inputs/outputs
3 DI_CO
M
Common terminal for digital inputs 23 Brake Motor holding brake control signal (for
SINAMICS V90 200 V variant only)
4 DI_CO
M
Common terminal for digital inputs 28 P24V_
DO
External 24 V supply for digital outputs
5
DI1
Digital input 1
29 *
DO4+
Digital output 4+
6
DI2
Digital input 2
30
DO1
Digital output 1
7
DI3
Digital input 3
31
DO2
Digital output 2
8
DI4
Digital input 4
32
DO3
Digital output 3
9
DI5
Digital input 5
33 *
DO4-
Digital output 4-
10
DI6
Digital input 6
34 *
DO5+
Digital output 5+
11
DI7
Digital input 7
35 *
DO6+
Digital output 6+
12
DI8
Digital input 8
44 *
DO5-
Digital output 5-
13
DI9
Digital input 9
49 *
DO6-
Digital output 6-
14 DI10 Digital input 10 50 MEXT_
DO
External 24 V ground for digital outputs
Analog inputs/outputs
18
P12AI
12 V power output for analog input
45
AO_M
Analog output ground
19
AI1+
Analog input channel 1, positive
46
AO1
Analog output channel 1
20
AI1-
Analog input channel 1, negative
47
AO_M
Analog output ground
21
AI2+
Analog input channel 2, positive
48
AO2
Analog output channel 2
22
AI2-
Analog input channel 2, negative
Refer to the following table for the original definitions of the above pins with an asterisk (*), wherein DO4 to DO6 are used for
the servo drive to support the wiring of
only
the NPN type.
Note
The original pin definitions are applicable only when the FS versio
n is as follows:
•
V90 200 V: FS01
•
V90 400 V: FS03 and the earlier
Refer to the rating plate on the drive housing for the FS version of a SINAMICS V90 servo drive.
Pin No.
Signal
Description
24
-
Reserved
25
-
Reserved
29
P24V_ DO
External 24 V supply for digital outputs
33
DO4
Digital output 4
34
DO5
Digital output 5
35
DO6
Digital output 6
44
-
Reserved
49
MEXT_ DO
External 24 V ground for digital outputs
