Siemens SIMOTICS S-1FL6 Getting Started

Getting Started
A5E36037886-003, 04/2017
83
Par. No.
Name
Min
Max
Factory
Setting
Unit
Data
type
Effective
Can be
changed
p1416 Speed setpoint filter 1
time constant
0.00 5000.00 0.00 ms Float IM T, U
Description: Sets the time constant for the speed setpoint filter 1 (PT1).
Dependency:
Refer to p1414, p1415
Note: This parameter is only effective if the filter is set as a PT1 low pass.
p1417 Speed setpoint filter 1
denominator natural fre-
quency
0.5 16000.0 1999.0 Hz Float IM T, U
Description: Sets the denominator natural frequency for speed setpoint filter 1(PT2, general filter).
Dependency: Refer to p1414, p1415
Note: This parameter is only effective if the speed filter is parameterized as a PT2 low pass or as general
filter.
The filter is only effective if the natural frequency is less than half of the sampling frequency.
p1418
Speed setpoint filter 1
denominator damping
0.001
10.000
0.700
-
Float
IM
T, U
Description: Sets the denominator damping for speed setpoint filter 1 (PT2, general filter).
Dependency: Refer to p1414, p1415
Note: This parameter is only effective if the speed filter is parameterized as a PT2 low pass or as general
filter.
p1419
Speed setpoint filter 1
numerator natural fre-
quency
0.5
16000.0
1999.0
Hz
Float
IM
T, U
Description: Sets the numerator natural frequency for speed setpoint filter 1 (general filter).
Dependency: Refer to p1414, p1415
Note:
This parameter is only effective if the speed filter is set as a general filter. The filter is only effective if the
natural frequency is less than half of the sampling frequency.
p1420
Speed setpoint filter 1
numerator damping
0.001
10.000
0.700
-
Float
IM
T, U
Description: Sets the numerator damping for speed setpoint filter 1 (general filter).
Dependency: Refer to p1414, p1415
Note: This parameter is only effective if the speed filter is set as a general filter.
p1421
Speed setpoint filter 2
type
0
2
0
-
I16
IM
T, U
Description: Sets the type for speed setpoint filter 2.
Dependency:
PT1 low pass: p1422
PT2 low pass: p1423, p1424
General filter: p1423 ... p1426
p1422
Speed setpoint filter 2
time constant
0.00
5000.00
0.00
ms
Float
IM
T, U
Description: Sets the time constant for the speed setpoint filter 2 (PT1).
Dependency: Refer to p1414, p1421
Note: This parameter is only effective if the speed filter is set as a PT1 low pass.
p1423 Speed setpoint filter 2
denominator natural fre-
quency
0.5 16000.0 1999.0 Hz Float IM T, U
Description: Sets the denominator natural frequency for speed setpoint filter 2 (PT2, general filter).
Dependency: Refer to p1414, p1421
Note:
This parameter is only effective if the speed filter is parameterized as a PT2 low pass or as general
filter.
The filter is only effective if the natural frequency is less than half of the sampling frequency.
