Siemens SIMOTION CX32-2

Supplementary system components
6.4 CBE30-2 Ethernet communication board
SIMOTION D4x5-2
Manual, 02/2012
113
6.4.8 Technical data
CBE30-2 technical data
Table 6- 16 CBE30-2 technical data
Characteristic Value
Current requirement at 24 V DC 0.25 A
Approvals cULus (File No. E164110)
Marking for Australia C-Tick mark
Storage and operation
Table 6- 17 Ambient conditions for CBE30-2
Characteristic Value/Range Standard
Permissible ambient temperature
• Storage
• Operation
-40° C... +70° C
0° C ... +55° C
Permissible relative humidity
(without condensation)
> 5 % to 95 % DIN EN 60721-3-3, Class 3K5
Degree of protection IP00 DIN EN 60529
Vibratory load DIN EN 60721-3-3, Class 3M6
Shock load DIN EN 60721-3-3, Class 3M4
Free fall DIN EN 60721-3-2, Class 2M1 and
2M2
Toppling DIN EN 60721-3-2, Class 2M1
Dimensions and weight
Characteristic Value
Dimensions (H x W x D) 25 x 95 x 143 mm
Weight 100 g
