6.7 Terminal module TM41
Properties of the TM41
With the TM41 terminal module, the number of available digital inputs/digital outputs and the
number of analog inputs within a drive system can be expanded. In addition, the TTL output
can be used for encoder emulation. The TM41 is connected via DRIVE-CLiQ.
The TM41 contains the following terminals:
Table 6- 37 Interface overview
Type Number
Digital inputs 4
Digital inputs/outputs 4
Analog inputs 1
TTL encoder output 1
CAUTION
The 50 mm clearances above and below the component must be observed.
Additional references
You will find detailed information about the TM41 terminal module in the
●
SINAMICS S120 Control Units and Additional System Components
Manual
●
SIMOTION D4x5-2
Commissioning and Hardware Installation Manual.
