Supplementary system components
6.4 CBE30-2 Ethernet communication board
SIMOTION D4x5-2
Manual, 02/2012
109
6.4.3 Safety information
CAUTION
The CBE30-2 may be inserted and removed only when the D4x5-2 Control Unit and the
CBE30-2 are in a de-energized state.
CAUTION
The CBE30-2 may be installed only by qualified personnel. The ESD notes must be
observed, see Section ESD guidelines (Page 143).
6.4.4 Interface description
Properties
The X1400 interface has full-duplex 10/100 Mbit Ethernet ports. The module has an
integrated 4-port switch.
Interface characteristics
Table 6- 13 X1400 features
Characteristic Type
Connector type RJ45 socket
Cable type Industrial Ethernet cable
Maximum cable length 100 m
Dust protection blanking plugs for sealing unused
PROFINET ports
Five blanking plugs contained in the D4x5-2
scope of delivery
Blanking plugs (50 pcs) order number:
6SL3066-4CA00-0AA0
