Interfaces
3.7 PROFIBUS DP interfaces
SIMOTION D4x5-2
66 Manual, 02/2012
3.7 PROFIBUS DP interfaces
Characteristics of the interface
Table 3- 16 Interfaces X126 and X136
Characteristics Type
Connector type 9-pin Sub-D socket
Cable type PROFIBUS cable
Max. cable length 100 m at 12 Mbit/s
Position of connectors
The following figure shows the mounting position and designation of the connectors on the
control unit.
'303,
;;
'3
Figure 3-8 The position of the PROFIBUS X126 and X136 interfaces (example of SIMOTION D4x5-
2 DP/PN)
