Description
1.9 CompactFlash card
SIMOTION D4x5-2
Manual, 02/2012
31
1.9 CompactFlash card
1.9.1 Usage and function of the CompactFlash Card
The CompactFlash card (CF card) is inserted in the slot with the designation CF (X109
interface).
&RPSDFW)ODVKFDUG
'[
2SHUDWRUFRQWUROVZLWKFRYHU
2SHUDWRUFRQWUROVZLWKRXWFRYHU
&RYHU
Figure 1-7 Slot for CompactFlash card
The CompactFlash card does not extend beyond the housing. An ergonomic recessed grip
enables the CompactFlash card to be removed.
