Siemens SIMOTION CX32-2

Supplementary system components
6.5 CX32-2 controller extension
SIMOTION D4x5-2
126 Manual, 02/2012
Communication
Table 6- 32 Interface communication
Data SIMOTION CX32-2
DRIVE-CLiQ interfaces 4
General technical data
Table 6- 33 Technical data (general)
Data SIMOTION CX32-2
Power supply
• Rated value
• Permissible range
24 VDC
(20.4 ... 28.8 V)
Current consumption, typically
1)
300 mA
Starting current, typical 1.6 A
Power loss, typical 7 W
Power loss, max. 14 W
1)
With no load on I/Os, no 24 V supply via DRIVE-CLiQ interface
Digital inputs
Table 6- 34 Digital inputs on SIMOTION CX32-2
Data SIMOTION CX32-2
Digital inputs 6
• Rated value
24 VDC
• For signal "1"
15 ... 30 V
• For signal "0"
2)
-3 ... +5 V
Galvanic isolation Yes, in groups of 6
1)
Current consumption typ. at High level 9 mA at 24 V
Input delay, typical (hardware) L -> H: 50 µs
H -> L: 150 µs
1)
The reference potential is terminal M1
2)
The digital inputs are protected against polarity reversal up to -30 V
