Operator control (hardware)
2.3 7-segment and LED displays
SIMOTION D4x5-2
Manual, 02/2012
45
Note
While the SIMOTION D4x5-2 is ramping up, all LEDs are briefly illuminated in yellow.
7-segment display
The 7-segment display provides further status information in addition to the LED displays.
The status "6" and a flashing "." indicate that the D4x5-2 has ramped up and communication
has been established to the SINAMICS Integrated.
Additional information
You can perform a detailed diagnosis with a PG/PC and the engineering system. Information
on the
Diagnostics
via LED displays can also be found in the
SIMOTION D4x5-2
Commissioning and Hardware Installation Manual and in the online help of this section via
the link under the
Instructions
menu.
