Interfaces
3.3 Ethernet interfaces
SIMOTION D4x5-2
Manual, 02/2012
53
Position of connectors for SIMOTION D4x5-2 DP/PN
The following figure shows the position of the Ethernet interfaces on the D4x5-2 DP/PN and
their displays.
\HOORZ
2II
RUDQJH
JUHHQ
2II
'DWDH[FKDQJH
1RGDWDH[FKDQJH
7UDQVIHUUDWH0ELWV
7UDQVIHUUDWHRUb0ELWV
1RRUIDXOW\FRQQHFWLRQ
6WDWXV'LVSOD\ 0HDQLQJ
'LVSOD\
'LVSOD\
'LVSOD\
'LVSOD\
;3
31,(
/,1.
$&7
;3
31,(1(7
/,1.
$&7
/,1.
$&7




Figure 3-3 The position of the Ethernet interfaces and their displays (example of SIMOTION D445-2 DP/PN)
Note
As of V4.3, the two Ethernet interfaces support the PROFINET basic services - they
therefore have the designation PN/IE-NET or PN/IE.
These PROFINET basic services (e.g. DCP, LLDP, SNMP) provide uniform functions for the
address assignment and diagnostics, but do not provide PROFINET IO communication for
the connection of drives, I/O modules, etc.
Additional references
Detailed information on the states of the status LEDs can be found in the SIMOTION D4x5-2
Commissioning and Hardware Installation Manual,
Diagnostics chapter.
