Interfaces
3.5 Digital I/Os
SIMOTION D4x5-2
Manual, 02/2012
63
Note
For optimal noise immunity of the digital inputs, the use of shielded cables is necessary if
they are to be used as
• Inputs of measuring inputs or
• Inputs for the external zero mark
Additional references
For information on configuring the digital I/Os as freely addressable I/Os, inputs of
measuring inputs or outputs of output cams, see the
SIMOTION D4x5-2
Commissioning and
Hardware Installation Manual.
For information on the configuration and function of the measuring input, output cam, and
cam track technology objects, refer to the
SIMOTION Output Cams and Measuring Inputs
Function Manual.
