Display Meaning Explanations
LED - flashing (2
Hz)
1)
Bus fault
● Failure of a connected I/O device.
● At least one of the assigned I/O devices cannot be addressed
● Incorrect or no configuration
Sync X11 (green)
2)
Sync status of PROFINET
interface
This LED indicates the synchronization status of the PROFINET interface
X11.
LED - OFF The PROFINET interface has not synchronized yet to the send cycle of IRT
or PROFINET with IRT has not been configured (e.g. only RT or TCP/IP
operation). If no PROFINET IO with IRT has been configured, then gener‐
ally there is no synchronization of the PROFINET interface. If isochronous
data has been configured for the SIMOTION device, the PROFINET inter‐
face generates a local substitute cycle of the same size as the configured
send cycle of IRT, as long as no synchronization has been performed to
the send cycle of IRT:
● The task system of SIMOTION has synchronized to the local substitute
cycle of the PROFINET interface.
● DP interfaces, if configured as isochronous, are synchronized to the
local substitute cycle of the PROFINET interface.
LED - flashing (2
Hz)
The PROFINET interface has synchronized to the send cycle of IRT. If
isochronous data has been configured for SIMOTION, then the following
applies:
● The task system of SIMOTION has synchronized to the send cycle of
IRT.
● DP interfaces, if configured as isochronous, have not synchronized yet
to the send cycle of IRT.
LED - ON The PROFINET interface has synchronized to the send cycle of IRT. If
isochronous data has been configured, then the following applies:
● The task system of SIMOTION has synchronized to the send cycle of
IRT.
● DP interfaces, if configured as isochronous, are synchronized to the
send cycle of IRT.
If no isochronous data has been configured for SIMOTION, this state indi‐
cates that only the PROFINET interface has synchronized to the send cycle
of IRT. The PROFINET interface is then used to forward the data.
Isochronous data means that data is exchanged with a further device on
PROFINET with configured RT class IRT and isochronous application/de‐
vice.
1) Minimum flashing duration 3 s
2) If no PROFINET IO with IRT has been configured, then generally no synchronization will be made to the send cycle.
Note
During ramp-up of the SIMOTION C, the LEDs on the housing front are briefly illuminated.
You can carry out a detailed diagnosis with a programming device or PC and the engineering
aystem.
Projects cannot be downloaded in STOPU mode.
Alarm, error, and system messages
10.1 Diagnosis using the LEDs
SIMOTION C
Operating Instructions, 11/2016, A5E33441428B 159
