Siemens simovert master drive User Manual

Transport, Unpacking, Installation 12.96
2-8 Siemens AG 6SE7087-6BM70
SIMOVERT MASTER DRIVES Operating Instructions
C (+)
D (-)
Master WR
Reactor
Slave WR
Fan assembly
Fan assembly
U
V
W
Incoming fuses F11, F12, F21, F22
Elektronics box with PMU
C
a
b
i
n
e
t
f
r
a
m
e
Incoming fuse F11, F12, F21, F22
U, V, W
SIMOVERT MASTER DRIVES Inverter Components, frame size: M (12) (Master, slave, reactor chassis) mounted in a cabinet frame (8MC)
Fig. 2.5 Type of construction M
