SIMOVERT MASTER DRIVES Operating Instructions
6.4 Isolating amplifiers
Input Output Order number
Option
Input isolating amplifiers for analog inputs
−
10 V to +10 V
−
10 V to +10 V 6SX7010-0AC00
−
20 mA to +20 mA
−
10 V to +10 V 6SX7010-0AC02
4 mA to +20 mA 4 mA to +20 mA 6SX7010-0AC01
Output isolating amplifiers for analog outputs
−
10 V to +10 V
−
10 V to +10 V 6SX7010-0AC00
−
10 V to +10 V
−
20 mA to +20 mA 6SX7010-0AC03
0 V to +10 V 4 mA to +20 mA 6SX7010-0AC04
Table 6.6 Overview of isolating amplifiers
6.5 Power section
Options Description/function
Braking unit For converting the regenerative energy into heat
Braking resistors Load resistor for the braking unit
Electrical DC link coupling Switching the DC-AC converter in and out under load
Mechanical DC link coupling Switching the DC-AC converter in and out in a no-voltage condition
Input rectifier Input rectifier for one or several DC-AC converters
Input rectifier with line-
commutated feedback
Supply rectifier for one or several DC-AC converters for motor or generator
operation
Table 6.7 Power section options
(+) 5
(-) 4
2 (+)
3 (-)
Input Output
6 (0 V) 1 (+24 V)
Power supply:
V = 24 V DC ±20 %
I = 90 mA
Fig. 6.2 Isolating amplifiers
