Siemens simovert master drive User Manual

08.96 Spare Parts
Siemens AG 6SE7087-6BM70
7-1
SIMOVERT MASTER DRIVES Operating Instructions
7 Spare Parts
7.1 Converter 510 V to 620 V DC
Part code No. Designation Order number No. Used in
+A10 -U1 (-A100, -A101, -A110, -A111, -A200, -A201,
-A210, -A211, -A300, -A301, -A310, -A311)
+A12 -U1 (-A100, -A101, -A110, -A111, -A200, -A201,
-A210, -A211, -A300, -A301, -A310, -A311)
IGBT transistor module 6SY7000-0AB70 24 6SE7041-1TM20
6SE7041-3TM20
+A10 -U1 (-A108, -A109, -A208, -A209, -A308, -A309)
+A12 -U1 (-A108, -A109, -A208, -A209, -A308, -A309)
SMU3 inverter snubber
board
6SE7038-6EK84-1GF0 12 6SE7041-1TM20
6SE7041-3TM20
+A10 -U1 (-A118, -A119, -A218, -A219, -A318, -A319)
+A12 -U1 (-A118, -A119, -A218, -A219, -A318, -A319)
SML3 inverter snubber
board
6SE7038-6EK84-
1GG0
12 6SE7041-1TM20
+A10 -U1 (-A19, -A29, -A39)
+A12 -U1 (-A19, -A29, -A39)
IGD8 inverter gating
board
6SE7037-0EK84-1JC0 6 6SE7041-1TM20
6SE7041-3TM20
+A10 -U1 (-C110, -C120)
+A12 -U1 (-C110, -C120)
MKP capacitor for the
fan
6SY7000-0AB64 4 6SE7041-1TM20
6SE7041-3TM20
+A10 -U1 (-E1, -E2)
+A12 -U1 (-E1, -E2)
Radial fan 6SY7000-0AB68 4 6SE7041-1TM20
6SE7041-3TM20
+A10 -U1 (-E1, -E2)
+A12 -U1 (-E1, -E2)
Nozzle for radial fan 6SY7000-0AB65 4 6SE7041-1TM20
+A10 -U1 (-E1, -E2)
+A12 -U1 (-E1, -E2)
Nozzle for radial fan 6SY7000-0AB65 4 6SE7041-3TM20
+A10 -U1 (-F101, -F102)
+A12 -U1 (-F101, -F102)
Fused load
disconnector
6SY7000-0AA26 4 6SE7041-1TM20
6SE7041-3TM20
+A10 -U1 (-F101, -F102)
+A12 -U1 (-F101, -F102)
Fuse insert 6SY7000-0AC34 4 6SE7041-1TM20
6SE7041-3TM20
+A10 -U1 (-F41, -F42, -F43, -F44)
+A12 -U1 (-F41, -F42, -F43, -F44)
Fuse insert 6SY7000-0AB75 8 6SE7041-1TM20
6SE7041-3TM20
+A10 -U1 (-R100, -R200, -R300)
+A12 -U1 (-R100, -R200, -R300)
Balancing resistor 6SY7000-0AB08 6 6SE7041-1TM20
6SE7041-3TM20
+A10 -U1 (-R108, -R109, -R118, -R119, -R208, -R209,
-R218, -R219, -R308, -R309, -R318, -R319)
+A12 -U1 (-R108, -R109, -R118, -R119, -R208, -R209,
-R218, -R219, -R308, -R309, -R318, -R319)
Snubber resistor 6SY7000-0AB18 24 6SE7041-1TM20
6SE7041-3TM20
+A10 -U1 -G25
+A12 -U1 -G25
PSU2 power supply
board
6SE7038-6GL84-1JA0 2 6SE7041-1TM20
6SE7041-3TM20
-G25 PSU2 power supply
board
6SE7038-6GL84-1JA0 1 6SE7035-1TJ20
6SE7036-0TK20
6SE7037-0TK20
6SE7038-6TK20
-G25 PSU2 power supply
board
6SE7038-6GL84-1JA1 1 6SE7041-1TK20
-A10 CU2 open- and closed-
loop control board (VC)
6SE7090-0XX84-0AF0 1 6SE7035-1TJ20
6SE7036-0TK20
6SE7037-0TK20
6SE7038-6TK20
6SE7041-1TK20
6SE7041-1TM20
6SE7041-3TM20
-A100, -A101, -A110, -A111, -A200, -A201, -A210, -A211,
-A300, -A301, -A310, -A311
IGBT transistor module 6SY7000-0AB70 12 6SE7036-0TK20
6SE7037-0TK20
-A100, -A101, -A110, -A111, -A200, -A201, -A210, -A211,
-A300, -A301, -A310, -A311
IGBT transistor module 6SY7000-0AA82 12 6SE7038-6TK20
