Spare Parts 08.96
7-2 Siemens AG 6SE7087-6BM70
SIMOVERT MASTER DRIVES Operating Instructions
Part code No. Designation Order number No. Used in
-A100, -A110, -A200, -A210, -A300, -A310 IGBT transistor module 6SY7000-0AB13 6 6SE7035-1TJ20
-A100, -A101, -A110, -A111, -A200, -A201, -A210, -A211,
-A300, -A301, -A310, -A311
IGBT transistor module 6SY7000-0AB13 12 6SE7041-1TK20
-A108, -A109, -A208, -A209, -A308, -A309 SMU3 inverter snubber
board
6SE7038-6EK84-1GF0 6 6SE7036-0TK20
6SE7037-0TK20
6SE7038-6TK20
6SE7041-1TK20
-A109, -A209, -A309 SMU3 inverter snubber
board
6SE7038-6EK84-1GF0 3 6SE7035-1TJ20
-A118, -A119, -A218, -A219, -A318, -A319 SML3 inverter snubber
board
6SE7038-6EK84-
1GG0
6 6SE7036-0TK20
6SE7037-0TK20
6SE7038-6TK20
6SE7041-1TK20
-A119, -A219, -A319 SML3 inverter snubber
board
6SE7038-6EK84-
1GG0
3 6SE7035-1TJ20
-A19, -A29, -A39 IGD8 inverter gating
board
6SE7037-0EK84-1JC0 3 6SE7036-0TK20
6SE7037-0TK20
-A19, -A29, -A39 IGD8 inverter gating
board
6SE7038-6EK84-1JC0 3 6SE7038-6TK20
6SE7041-1TK20
-A20 IVI inverter interface
board
6SE7038-6GL84-1BG0 1 6SE7035-1TJ20
6SE7036-0TK20
6SE7037-0TK20
6SE7038-6TK20
-A20 IVI inverter interface
board
6SE7038-6GL84-1BG2 1 6SE7041-1TK20
-A22 IPI parallel switching
board
6SE7090-0XX84-1CE0 1 6SE7041-1TM20
6SE7041-3TM20
-A25 ABI normalization board 6SE7041-1TM84-1CF0 1 6SE7041-1TM20
-A25 ABI normalization board 6SE7041-3TM84-1CF0 1 6SE7041-3TM20
-A26 ABO normalization
board
6SE7035-1EJ84-1BH0 1 6SE7035-1TJ20
-A26 ABO normalization
board
6SE7036-0TK84-1BH0 1 6SE7036-0TK20
-A26 ABO normalization
board
6SE7037-0EK84-1BH0 1 6SE7037-0TK20
-A26 ABO normalization
board
6SE7038-6EK84-1BH0 1 6SE7038-6TK20
-A26 ABO normalization
board
6SE7041-1TK84-1BH0 1 6SE7041-1TK20
-A29 IGD7 inverter gating
board
6SE7035-1EJ84-1JC0 1 6SE7035-1TJ20
-A30 PMU operator
control/parameterizing
unit
6SE7090-0XX84-2FA0 1 6SE7035-1TJ20
6SE7036-0TK20
6SE7037-0TK20
6SE7038-6TK20
6SE7041-1TK20
6SE7041-1TM20
6SE7041-3TM20
DC link capacitors,
complete with mounting
assembly
6SY7000-0AC31 3 6SE7035-1TJ20
DC link capacitors,
complete with mounting
assembly
6SY7000-0AC25 3 6SE7036-0TK20
6SE7037-0TK20
DC link capacitors,
complete with mounting
assembly
6SY7000-0AC26 3 6SE7038-6TK20
