08.96 Spare Parts
Siemens AG 6SE7087-6BM70
7-3
SIMOVERT MASTER DRIVES Operating Instructions
Part code No. Designation Order number No. Used in
DC link capacitors,
complete with mounting
assembly
6SY7000-0AC25 6 6SE7041-1TM20
6SE7041-3TM20
DC link capacitors,
complete with mounting
assembly
6SY7000-0AC65 3 6SE7041-1TK20
-C110 MKP capacitor for the
fan
6SY7000-0AB64 1 6SE7035-1TJ20
-C110, -C120 MKP capacitor for the
fan
6SY7000-0AB64 2 6SE7036-0TK20
6SE7037-0TK20
6SE7038-6TK20
-C110, -C120 MKP capacitor for the
fan
6SY7000-0AC38 2 6SE7041-1TK20
-E1 Nozzle for the radial fan 6SY7000-0AB65 1 6SE7035-1TJ20
-E1 Radial fan 6SY7000-0AB68 1 6SE7035-1TJ20
-E1, -E2 Nozzle for the radial fan 6SY7000-0AB65 2 6SE7036-0TK20
6SE7037-0TK20
6SE7038-6TK20
-E1, -E2 Nozzle for the radial fan 6SY7000-0AC41 2 6SE7041-1TK20
-E1, -E2 Radial fan 6SY7000-0AB68 2 6SE7036-0TK20
6SE7037-0TK20
6SE7038-6TK20
-E1, -E2 Radial fan 6SY7000-0AC40 2 6SE7041-1TK20
-F101, -F102 Fused load
disconnector
6SY7000-0AA26 2 6SE7035-1TJ20
6SE7036-0TK20
6SE7037-0TK20
6SE7038-6TK20
6SE7041-1TK20
-F101, -F102 Fuse insert 6SY7000-0AC34 2 6SE7035-1TJ20
6SE7036-0TK20
6SE7037-0TK20
6SE7038-6TK20
-F101, -F102 Fuse insert 6SY7000-0AC42 2 6SE7041-1TK20
-F41, -F42, -F43, -F44 Fuse insert 6SY7000-0AB75 4 6SE7036-0TK20
6SE7037-0TK20
6SE7035-1TJ20
-F41, -F42, -F43, -F44 Fuse insert 6SY7000-0AB88 4 6SE7038-6TK20
-F41, -F42, -F43, -F44 Fuse insert 6SY7000-0AC64 4 6SE7041-1TK20
-R100, -R200, -R300 Balancing resistor 6SY7000-0AB08 3 6SE7036-0TK20
6SE7037-0TK20
-R100, -R200, -R300 Balancing resistor 6SY9705 3 6SE7035-1TJ20
-R100, -R200, -R300 Balancing resistor 6SY7000-0AA77 3 6SE7038-6TK20
-R100, -R200, -R300 Balancing resistor 6SY7000-0AA76 3 6SE7041-1TK20
-R108, -R109, -R118, -R119, -R208, -R209, -R218, -
R219, -R308, -R309, -R318, -R319
Snubber resistor 6SY7000-0AB18 12 6SE7036-0TK20
6SE7037-0TK20
6SE7038-6TK20
6SE7041-1TK20
-R109, -R119, -R209, -R219, -R309, -R319 Snubber resistor 6SY7000-0AB18 6 6SE7035-1TJ20
OPTION L31: +A10 -U1 (-F41, -F42, -F43, -F44),+A12
-U1 (-F41, -F42, -F43, -F44)
Fuse insert 6SY7000-0AC03 8 6SE7041-1TM20
6SE7041-3TM20
OPTION L31: -F41, -F42, -F43, -F44 Fuse insert 6SY7000-0AC20 4 6SE7038-6TK20
OPTION L31: -F41, -F42, -F43, -F44 Fuse insert 6SY7000-0AC05 4 6SE7035-1TJ20
OPTION L31: -F41, -F42, -F43, -F44 Fuse insert 6SY7000-0AC03 4 6SE7036-0TK20
6SE7037-0TK20
