Options 08.96
6-2 Siemens AG 6SE7087-6BM70
SIMOVERT MASTER DRIVES Operating Instructions
The options are supplied with the option description.
Desig-
nation
Description Order No.
LBA Local bus adapter for the electronics box. This is
required for installing T300, CB1, TSY, SCB1 and SCB2
Board
description
6SE7090-0XX84-4HA0
6SE7087-6CX84-4HA0
T300 Technology board for controlling technological
processes
Board
description
6SE7090-0XX84-0AH0
6SE7087-6CX84-0AH0
TSY Synchronizing board Board
description
6SE7090-0XX84-0BA0
6SE7087-6CX84-0BA0
SCB1 Serial communications board with fiber-optic cable for
serial I/O system and peer-to-peer connection
Board
description
6SE7090-0XX84-0BC0
6SE7087-6CX84-0BC0
SCB2 Serial communications board for peer-to-peer
connection and USS protocol via RS485
Use of the serial interface with USS protocol
Board
description
Application
description
6SE7090-0XX84-0BD0
6SE7087-6CX84-0BD0
6SE7087-6CX87-4KB0
CB1 Communications board with interface for SINEC- L2-DP,
(Profibus)
Use of the PROFIBUS DP interface
Board
description
Application
description
6SE7090-0XX84-0AK0
6SE7087-6CX84-0AK0
6SE7087-6CX87-0AK0
Table 6.2 Option boards and bus adapter
If the converter is supplied through an external main
contactor, the option board in the electronics box must
be supplied from an external power supply, according
to Table 6.3.
These values are required in addition to the current
drawn by the basic converter (
+
section “Technical
Data“).
Board Current drain (mA)
CB1 190
SCB1 50
SCB2 150
TSY w/out tacho 150
T300 w/out tacho 620
Standard tacho
Type: 1PX 8001-1
I
0
95
(190 at 6000 RPM)
Table 6.3 Current drain of the option boards
