08.96 Spare Parts
Siemens AG 6SE7087-6BM70
7-5
SIMOVERT MASTER DRIVES Operating Instructions
Part code No. Designation Order No. No. Used in
+A10 -U1 (-E1, -E2),
+A12 -U1 (-E1, -E2)
Nozzle for radial fan 6SY7000-0AB65 4 6SE7041-2UM20
+A10 -U1 (-F101, -F102),
+A12 -U1 (-F101, -F102)
Fused load
disconnector
6SY7000-0AA26 4 6SE7041-0UM20
6SE7041-1UM20
6SE7041-2UM20
6SE7041-4UM20
6SE7041-6UM20
+A10 -U1 (-F101, -F102),
+A12 -U1 (-F101, -F102)
Fuse insert 6SY7000-0AC34 4 6SE7041-0UM20
6SE7041-1UM20
6SE7041-2UM20
+A10 -U1 (-F101, -F102),
+A12 -U1 (-F101, -F102)
Fuse insert 6SY7000-0AC42 4 6SE7041-4UM20
6SE7041-6UM20
+A10 -U1 (-F41, -F42, -F43, -F44),
+A12 -U1 (-F41, -F42, -F43, -F44)
Fuse insert 6SY7000-0AB77 8 6SE7041-0UM20
6SE7041-1UM20
+A10 -U1 (-F41, -F42, -F43, -F44),
+A12 -U1 (-F41, -F42, -F43, -F44)
Fuse insert 6SY7000-0AB87 8 6SE7041-2UM20
+A10 -U1 (-F41, -F42, -F43, -F44),
+A12 -U1 (-F41, -F42, -F43, -F44)
Fuse insert 6SY7000-0AB74 8 6SE7041-4UM20
6SE7041-6UM20
+A10 -U1 (-R100, -R200, -R300),
+A12 -U1 (-R100, -R200, -R300)
Balancing resistor 6SY7000-0AA77 6 6SE7041-0UM20
6SE7041-1UM20
6SE7041-2UM20
+A10 -U1 (-R100, -R200, -R300),
+A12 -U1 (-R100, -R200, -R300)
Balancing resistor 6SY7000-0AA76 6 6SE7041-4UM20
6SE7041-6UM20
+A10 -U1 (-R108, -R109, -R118, -R119, -R208, -R209,
-R218, -R219, -R308, -R309, -R318, -R319)
+A12 -u1 (-r108, -r109, -r118, -r119, -r208, -r209, -r218,
-r219, -r308, -r309, -r318, -r319)
Snubber resistor 6SY7000-0AB18 24 6SE7041-0UM20
6SE7041-1UM20
6SE7041-2UM20
6SE7041-4UM20
6SE7041-6UM20
+A10 -U1 -A28,
+A12 -U1 -A28
VDU voltage distribution
board
6SE7038-6GL84-1JB0 2 6SE7041-0UM20
6SE7041-1UM20
6SE7041-2UM20
6SE7041-4UM20
6SE7041-6UM20
+A10 -U1 -G25,
+A12 -U1 -G25
PSU2 power supply
board
6SE7038-6GL84-1JA0 2 6SE7041-0UM20
6SE7041-1UM20
6SE7041-2UM20
6SE7041-4UM20
6SE7041-6UM20
G25 PSU2 power supply
board
6SE7038-6GL84-1JA0 1 6SE7033-0UJ20
6SE7033-5UJ20
6SE7034-5UK20
6SE7035-7UK20
6SE7036-5UK20
6SE7038-6UK20
+A10 -U1 -R28,
+A12 -U1 -R28
VDU resistor 6SY7000-0AC33 2 6SE7041-0UM20
6SE7041-1UM20
6SE7041-2UM20
6SE7041-4UM20
6SE7041-6UM20
