Spare Parts 08.96
7-14 Siemens AG 6SE7087-6BM70
SIMOVERT MASTER DRIVES Operating Instructions
Part code No. Designation Order No. No. Used in
-R108, -R109, -R118, -R119, -R208, -R209, -R218, -
R219, -R308, -R309, -R318, -R319
Snubber resistor 6SY7000-0AB18 12 6SE7034-5WK20
6SE7035-7WK20
6SE7036-5WK20
6SE7038-6WK20
-R109, -R119, -R209, -R219, -R309, -R319 Snubber resistor 6SY7000-0AB18 6 6SE7033-0WJ20
6SE7033-5WJ20
-R28 VDU resistor 6SY7000-0AC33 1 6SE7033-0WJ20
6SE7033-5WJ20
6SE7034-5WK20
6SE7035-7WK20
6SE7036-5WK20
6SE7038-6WK20
OPTION L31: +A10 -U1 (-F41, -F42, -F43, -F44),
+A12 -U1 (-F41, -F42, -F43, -F44)
Fuse insert 6SY7000-0AC16 8 6SE7041-0WM20
6SE7041-1WM20
6SE7041-2WM20
OPTION L31: +A10 -U1 (-F41, -F42, -F43, -F44),
+A12 -U1 (-F41, -F42, -F43, -F44)
Fuse insert 6SY7000-0AC20 8 6SE7041-4WM20
6SE7041-6WM20
OPTION L31: -F41, -F42 Fuse insert 6SY7000-0AC17 2 6SE7033-0WJ20
6SE7033-5WJ20
6SE7034-5WK20
OPTION L31: -F41, -F42, -F43, -F44 Fuse insert 6SY7000-0AC16 4 6SE7035-7WK20
6SE7036-5WK20
OPTION L31: -F41, -F42, -F43, -F44 Fuse insert 6SY7000-0AC20 4 6SE7038-6WK20
ACCESSORIES Connector set,
SIMOVERT VC
6SY7000-0AC13 1 6SE7033-0WJ20
6SE7033-5WJ20
6SE7034-5WK20
6SE7035-7WK20
6SE7036-5WK20
6SE7038-6WK20
6SE7041-0WM20
6SE7041-1WM20
6SE7041-2WM20
6SE7041-4WM20
6SE7041-6WM20
