Technical data
10.3 Technical data, Power Modules
Inverter with CU240B-2 and CU240E-2 Control Units
282 Operating Instructions, 07/2010, FW 4.3.2, A5E02299792B AA
Power-dependent data, PM260 - IP20
Table 10- 19 PM260 frame size D, 3-ph. 660 V AC… 690 V, ± 10% (500 V - 10%)
Order number with filter
without filter
6SL3225- 0BH27-5AA1
6SL3225- 0BH27-5UA1
6SL3225- 0BH31-1AA1
6SL3225- 0BH31-1UA1
6SL3225- 0BH31-5AA1
6SL3225- 0BH31-5UA1
Values based on Low Overload
● LO power
● LO input current
● LO output current
11 kW
13 A
14 A
15 kW
18 A
19 A
18.5 kW
22 A
23 A
Values based on High Overload
● HO power
● HO input current
● HO output current
7.5 kW
10 A
10 A
11 kW
13 A
14 A
15 kW
18 A
19 A
General values
● Power loss
● Fuse
● Cooling air requirement
● Cable cross-section for line and
motor connection
● Torque for line and
motor connection
● Weight with filter
● without filter
No data
25 A
44 l/s
2.5 … 16 mm
2
1.5 Nm
23 kg
22 kg
No data
35 A
44 l/s
2.5 … 16 mm
2
1.5 Nm
23 kg
22 kg
No data
35 A
44 l/s
2.5 … 16 mm
2
1.5 Nm
23 kg
22 kg
Table 10- 20 PM260 frame size F, 3-ph. 660 V AC… 690 V, ± 10% (500 V - 10%)
Order number with filter
without filter
6SL3225- 0BH32-2AA1
6SL3225- 0BH32-2UA1
6SL3225- 0BH33-0AA1
6SL3225- 0BH33-0UA1
6SL3225- 0BH33-7AA1
6SL3225- 0BH33-7UA1
Values based on Low Overload
● LO power
● LO input current
● LO output current
30 kW
34 A
35 A
37 kW
41 A
42 A
55 kW
60 A
62 A
Values based on High Overload
● HO power
● HO input current
● HO output current
22 kW
26 A
26 A
30 kW
34 A
35 A
37 kW
41 A
42 A
General values
● Power loss
● Fuse
● Cooling air requirement
● Cable cross-section for line and
motor connection
● Torque for line and
motor connection
● Weight with filter
● without filter
No data
63 A
130 l/s
10 … 35 mm
2
6 Nm
58 kg
56 kg
No data
80 A
130 l/s
10 … 35 mm
2
6 Nm
58 kg
56 kg
No data
100 A
130 l/s
10 … 35 mm
2
6 Nm
58 kg
56 kg
