Accessories
8.10 Output reactor
Power Module PM240-2
148 Hardware Installation Manual, 01/2020, A5E33294624B AL
Dimensions, drilling patterns and weights for FSD … FSG converters
Figure 8-7 Dimensions and drilling patterns
Table 8- 12 Dimensions and weights
Article number
Induct-
ance
[mH]
Overall dimensions
[mm]
Drilling dimensions
[mm]
Fixing/torque
[Nm]
Weight
[kg]
W
H
D
b
t1
t2
6SE6400-3TC07-5ED0
/
270
248
209
200
102
91.5
4 x M8 / 25
26.5
6SE6400-3TC14-5FD0
/
350
321
288
264
140
134
4 x M8 / 25
57
6SL3000-2BE32-1AA0
/
300
285
257
224
165
78
4 x M8 / 25
60
6SL3000-2BE32-6AA0
/
300
315
277
224
185
78
4 x M8 / 25
66
6SL3000-2BE33-2AA0
/
300
285
277
224
183
79
4 x M8 / 25
66
6SL3000-2BE33-8AA0
/
300
285
277
224
183
79
4 x M8 / 25
73
6SL3000-2BE35-0AA0
/
300
365
277
224
183
79
4 x M8 / 25
100
JTA:TEU2532-0FP00-
4EA0
1.5 264 255 131 249 101 / 4 x M6 / 10 18
JTA:TEU 9932-0FP00-
4EA0
1.2 264 270 159 129 129 / 4 x M6 / 10 26
JTA:TEU 9932-0FS00-
0EA0
0.9 310 370 182 289 142 / 4 x M8 / 25 42
JTA:TEU 9932-1FC00-
1BA0
0.53 400 320 193 379 150 / 4 x M8 / 25 66
JTA:TEU 9932-0FV00-
1BA0
0.37 400 355 193 379 150 / 4 x M8 / 25 90
JTA:TEU 4732-0FA00-
0BA0
0.22 460 430 251 356 212 / 4 x M12 / 50 162
The output reactors have a protection rating of IP00.
