Technical data
6.5 400 V converters
Power Module PM240-2
96 Hardware Installation Manual, 01/2020, A5E33294624B AL
Table 6- 28 PM240-2, IP20, frame size F, 380 V … 480 V 3 AC
Article No. without filter
Article No. with filter
6SL3210-1PE32-5UL0
6SL3210-1PE32-5AL0
LO base load power 132 kW
LO base load input current 242 A
LO base load output current 250 A
HO base load power
110 kW
HO base load input current
218 A
HO base load output current 205 A
Fuse according to IEC
Fuse according to UL, class J
3NA3252 (315 A)
350 A
Power loss without filter
2.98 kW
Power loss with filter
3.02 kW
Required cooling air flow
153 l/s
Weight without filter
62 kg
Weight with filter
66 kg
Table 6- 29 PM240-2, PT, frame size F, 380 V … 480 V 3 AC
Article No. without filter
Article No. with filter
6SL3211-1PE32-5UL0
6SL3211-1PE32-5AL0
LO base load power
132 kW
LO base load input current
242 A
LO base load output current
250 A
HO base load power
110 kW
HO base load input current
218 A
HO base load output current 205 A
Fuse according to IEC
Fuse according to UL, class J
3NA3252 (315 A)
350 A
Power loss without filter
2.98 kW
1)
Power loss with filter 3.02 kW
1)
Required cooling air flow 153 l/s
Weight without filter
63.5 kg
Weight with filter
68.5 kg
1)
Approx. 2.6 kW through the heatsink
