Setpoint channel
Function diagrams
2-567
© Siemens AG 2011 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 01/2011
2.7 Setpoint channel
Function diagrams
3010 – Fixed speed setpoints, binary selection (p1016 = 2) 2-568
3011 – Fixed speed setpoints, direct selection (p1016 = 1) 2-569
3020 – Motorized potentiometer 2-570
3030 – Main/supplementary setpoint, setpoint scaling, jogging 2-571
3040 – Direction limitation and direction reversal 2-572
3050 – Skip frequency bands and frequency limitations 2-573
3060 – Basic ramp-function generator 2-574
3070 – Extended ramp-function generator 2-575
3080 – Ramp-function generator selection, status word, tracking 2-576
