Free Function Blocks
Function diagrams
2-601
© Siemens AG 2011 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 01/2011
2.10 Free Function Blocks
Function diagrams
7200 – Run-time groups / Sampling times 2-602
7210 – AND (AND function block with 4 inputs) 2-603
7212 – OR (OR function block with 4 inputs) 2-604
7214 – XOR (XOR function block with 4 inputs) 2-605
7216 – NOT (inverter) 2-606
7220 – ADD (adder with 4 inputs), SUB (subtracter) 2-607
7222 – MUL (multiplier), DIV (divider) 2-608
7224 – AVA (absolute value generators) 2-609
7225 – NCM (numerical comparator) 2-610
7226 – PLI (scaling polyline) 2-611
7230 – MFP (pulse generator), PCL (pulse shortener) 2-612
7232 – PDE (switch-in delay) 2-613
7233 – PDF (switch-out delay) 2-614
7234 – PST (pulse extender) 2-615
7240 – RSR (RS flipflop), DFR (D flipflop) 2-616
7250 – BSW (binary changeover switch), NSW (numerical changeover switch) 2-617
7260 – LIM (limiter) 2-618
7262 – PT1 (smoothing element) 2-619
7264 – INT (integrator), DIF (differentiating element) 2-620
7270 – LVM (limit value monitor, double-sided with hysteresis) 2-621
