Free Function Blocks
Function diagrams
2-603
© Siemens AG 2011 All Rights Reserved SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 01/2011
Bild 2-93 7210 – AND (AND function block with 4 inputs)
- 7210 -
Function diagram
87654321
FP_7210_97_51.vsd
Logic function blocks
G120 CU230P-2
13.12.2010 V4.4
AND (AND function block with 4 inputs)
AND 1
AND 0
AND 3
AND 2
I0
I1
I2
I3
Q
[0]
AND 0 inputs
p20030
[1]
[2]
[3]
AND 0 output Q
r20031
AND 0 RTG
1 ... 9999
p20032 (9999)
AND 0 RunSeq
0 ... 32000
p20033 (10)
I0
I1
I2
I3
Q
[0]
AND 2 inputs
p20038
[1]
[2]
[3]
AND 2 output Q
r20039
AND 2 RTG
1 ... 9999
p20040 (9999)
AND 2 RunSeq
0 ... 32000
p20041 (30)
I0
I1
I2
I3
Q
[0]
AND 1 inputs
p20034
[1]
[2]
[3]
AND 1 output Q
r20035
AND 1 RTG
1 ... 9999
p20036 (9999)
AND 1 RunSeq
0 ... 32000
p20037 (20)
I0
I1
I2
I3
Q
[0]
AND 3 inputs
p20042
[1]
[2]
[3]
AND 3 output Q
r20043
AND 3 RTG
1 ... 9999
p20044 (9999)
AND 3 RunSeq
0 ... 32000
p20045 (40)
