Compliance with standards
Standards EN 50274, EN 60146-1, EN 60204-1, EN 60529, EN 61800-2, EN 61800-3, EN 61800-5-1
CE mark EMC Directive 2004/108/EC
Low Voltage Directive 2006/95/EC
Machinery directive 2006/42/EC for functional safety
Radio interference suppression According to EMC product standard for variable speed drives EN 61800-3,
Second environment (optionally, the first environment)
Environmental conditions
During storage During transport During operation
Ambient temperature -25 °C to +55 °C -25 °C to +70 °C
from
-40 °C
2)
for 24 hours
0° C
2)
... +40° C
to +50° C see derating data
Relative air humidity
(condensation not permissible)
Corresponds to class
5 %
2)
... 95 %
2)
1K4 to EN 60721-3-1
5 % ... 95 % at 40 °C
2K3 according to EN 60
721-3-2
5 % ...
95 %
2)
3K3 according to EN
60721-3-3
Installation altitude
● Motor Modules in Booksize Cabinet Kit format:
Up to 1000 m above sea level without derating
> 1000 m, see characteristics/derating data
●
Cabinet Modules:
Up to 2000 m above sea level without derating
> 2000 m, see characteristics/derating data
2)
Deviations from the specified class are shown in
italics
.
Cooling circuit
Maximum system pressure with
respect to atmosphere
600 kPa
Temperature of the coolant when
it
enters the converter cooling cir‐
cuit
Dependent on the ambient temperature, condensation not permitted
● 0 °C … 45 °C without derating, 45 °C … 50 °C see derating characteristics
● Antifreeze is mandatory for the temperature range between 0 °C … 5 °C;
recommended antifreeze: Antifrogen N and Antifrogen L from the Clariant company.
Mechanical strength
During storage During transport During operation
Vibratory load
Deflection
Acceleration
Corresponds to class
1.5 mm at
5 Hz
3)
... 9 Hz
5 m/s² at > 9 ... 200 Hz
1M2 according to EN
60721-3-1
3.1 mm at
5 Hz
3)
... 9 Hz
10 m/s² at > 9 ... 200 Hz
2M2 according to EN
60721-3-2
0.075 mm at 10 ... 58 Hz
9.8 m/s² at > 58 ... 200 Hz
-
Shock stressing
Acceleration
Corresponds to class
40 m/s
2
for 22 ms
1M2 according to EN
60721-3-1
100 m/s
2
for 11 ms
2M2 according to EN
60721-3-2
100 m/s
2
for 11 ms
3M4 according to EN
60721-3-3
3)
Deviations from the specified class are shown in
italics
.
Technical data
B.1 General technical system data
Applications for Cabinet Modules, liquid cooled
142 Operating Instructions, 04/2015, A5E35974555A
