Siemens SINAMICS SM150 - Table 8-6 Leds of the DM10 Diagnostics Module

LED Color Status Description; cause Remedy
RUN /
ERR
- Off The electronic power supply is missing or
lies outside the permissible tolerance
range.
-
Green Continuous
light
The component is ready for operation
and cyclic DRIVE-CLiQ communication
is in progress.
-
Orange Continuous
light
DRIVE-CLiQ communication is being es‐
tablished.
-
Red Continuous
light
At least one fault is present in the com‐
ponent.
LED is controlled irrespective of the cor‐
responding messages being reconfig‐
ured.
Remedy and acknowledge fault.
Green/red 0.5 Hz flashing
light
Firmware download in progress. -
2 Hz flashing
light
Firmware download is complete. Waiting
for POWER ON.
Carry out a POWER ON.
Green/
orange
or
Red/orange
Flashing light Component recognition via LED is acti‐
vated.
The color depends on the LED state
when component recognition is activated.
-
LEDs of the DM10 diagnostics module
The LEDS installed on the diagnosis module indicate the logic state of the signals present
between the communication partners of the DM10 diagnosis module.
Table 8-6 LEDs of the DM10 diagnostics module
LED Communication partner Meaning: signal 1 / signal 0
H30 -X232/-X32 Control signals from PSA present / not present
H31 -X232/-X32 Control signals from PSA present / not present
H32 -X232/-X32 Control signals from PSA present / not present
H33 -X232/-X32 Control signals from PSA present / not present
H34 -X33/-X5 Binary plant signals for diagnosis on PADU8 present / not present
H35 -X33/-X5 Binary plant signals for diagnosis on PADU8 present / not present
H36 -X33/-X5 Binary plant signals for diagnosis on PADU8 present / not present
H37 -X33/-X5 Binary plant signals for diagnosis on PADU8 present / not present
H20 -X34/-X36 Internal power supply 1P24 OK / not OK
H21 -X34/-X36 Internal power supply 1N24 OK / not OK
H22 -X35/-X36 External power supply 2P24_1 and 2P24_2 OK / 2P24_1 or 2P24_2 not OK
H23 - Internal and external power supplies OK / not OK
