8.6.3.3 Diagnostics via parameters
Diagnostic parameters for the device status
r0002 Drive status
Display of drive status
r0046 Missing drive enable signals
Display of the missing enable signals that prevent the drive control from being commissioned
Bit Signal name 0-signal 1-signal
00 OFF1 enable missing No Yes
01 OFF2 enable missing No Yes
02 OFF3 enable missing No Yes
03 Enable run missing No Yes
05 External power-on inhibit active No Yes
06 Commissioning not yet complete No Yes
09 Infeed enable missing No Yes
10 Ramp-function generator enable missing No Yes
11 Ramp-function generator start missing No Yes
12 Setpoint enable missing No Yes
13 PSA pulse inhibit due to undervoltage No Yes
14 Operation enable from automatic restart function No Yes
16 OFF1 internal enable missing No Yes
17 OFF2 internal enable missing No Yes
18 OFF3 internal enable missing No Yes
19 Pulse enable internal missing No Yes
24 Motor data set changeover active No Yes
25 Function bypass active No Yes
26 Drive inactive or not operational No Yes
r0050 Active command data set (CDS)
Display of the active command data set (Command Data Set, CDS)
Bit Signal name 0-signal 1-signal
00 CDS effective, bit 0 No Yes
01 CDS effective, bit 1 No Yes
02 CDS effective, bit 2 No Yes
03 CDS effective, bit 3 No Yes
You can find additional notes in the parameter description of parameters p0810, p0811, r0836 in the List Manual.
The command data set selected via the binector inputs (e.g. p0810) is displayed via r0836.
