Communicating with the PLC
6.2 MODBUS communication
SINAMICS V20 Inverter
Operating Instructions, 07/2012, A5E03728167
111
The table below shows the cases in which an Exception Code is returned:
Error description Exception Code
Unknown Function Code 01
Read registers, which are out of boundary 02
Write register, which is out of boundary 02
Read request of too many registers (>125) 03
Write request of too many registers (>123) 03
Incorrect message length 03
Write to a read-only register 04
Write register, error in parameter access 04
Read register, error in Parameter Manager 04
Write to a zero entry 04
Unknown error 04
Basic inverter settings
Parameter Function Setting
P0010 Commissioning parameter = 30: restores to factory settings
P0970 Factory reset Possible settings:
= 1: resets all parameters (not user defaults) to their default
values
= 21: resets all parameters and all user defaults to factory
reset state
Note: Parameters P2010, P2021, P2023 retain their values
after a factory reset.
P0003 User access level = 3
P0700 Selection of command source = 5: USS / MODBUS on RS485
Factory default: 1 (operator panel)
P2010[0] USS / MODBUS baudrate Possible settings:
= 6: 9600 bps
= 7: 19200 bps
= 8: 38400 bps (factory default)
...
=12 115200 bps
P2014[0] USS / MODBUS telegram off time [ms] By default (time set to 0), no fault is generated (i.e.
watchdog disabled).
P2021 Modbus address Sets the unique address for the inverter.
Range: 1 ... 247 (factory default: 1)
P2022 Modbus reply timeout [ms] Range: 0 ... 10000 (factory default: 1000)
P2023 RS485 protocol selection = 2: Modbus
Factory default: 1 (USS)
Note: After changing P2023, powercycle the inverter.
During the powercycle, wait until LED has gone off or the
display has gone blank (may take a few seconds) before
re-applying power. If P2023 has been changed via a PLC,
make sure the change has been saved to EEPROM via
P0971.
