Parameter list
7.2 Parameter list
SINAMICS V20 Inverter
148 Operating Instructions, 07/2012, A5E03728167
Parameter Function Range Factory
default
Can be
changed
Scaling Data
set
Data
type
Acc.
Level
Bit Signal name 1 signal 0 signal
00 Signal lost on AI1 Yes No
01 Signal lost on AI2 Yes No
08 No signal lost on AI1 Yes No
09 No signal lost on AI2 Yes No
r0752[0...1] Actual analog input [V] or
[mA]
- - - - - Float 2
Displays smoothed analog input value in volts or million amps before the scaling block.
Index: [0] Analog input 1 (AI1)
[1] Analog input 2 (AI2)
P0753[0...1] Smooth time analog
input [ms]
0 - 10000 3 U, T - - U16 3
Defines filter time (PT1 filter) for analog input.
Index: See r0752
Note: Increasing this time (smooth) reduces jitter but slows down response to the analog input.
P0753 = 0: No filtering
r0754[0...1] Actual analog input value
after scaling [%]
- - - - - Float 2
Shows smoothed value of analog input after scaling block.
Index: See r0752
Dependency: P0757 to P0760 define range (analog input scaling).
r0755[0...1] CO: Actual analog input
after scaling [4000h]
- - - - 4000H I16 2
Displays analog input, scaled using ASPmin and ASPmax (ASP = analog setpoint).
Analog setpoint (ASP) from the analog scaling block can vary from minimum analog setpoint (ASPmin) to
a maximum analog setpoint (ASPmax).
The largest magnitude (value without sign) of ASPmin and ASPmax defines the scaling of 16384.
By associating r0755 with an internal value (e.g. frequency setpoint), a scaled value is calculated internally
by the inverter.
The frequency value is calculated using the following equation:
r0755 [Hz] = (r0755 [hex] / 4000 [hex]) * P2000 * (max (|ASP_max|, |ASP_min|) / 100%)
Example: Case a:
ASPmin = 300 %, ASPmax = 100 % then 16384 represents 300 %.
This parameter will vary from 5461 to 16384.
Case b:
ASPmin = -200 %, ASPmax = 100 % then 16384 represents 200 %.
This parameter will vary from -16384 to +8192.
