Parameter list
7.2 Parameter list
SINAMICS V20 Inverter
152 Operating Instructions, 07/2012, A5E03728167
Parameter Function Range Factory
default
Can be
changed
Scaling Data
set
Data
type
Acc.
Level
P0802 Transfer data from
EEPROM
0 - 2 0 - - - U16 3
Transfers values from inverter to External device when none 0. P0010 must be set to 30 for this to be
possible.
0 Disabled
2 Start MMC Transfer
Note: Parameter is automatically reset to 0 (default) after transfer.
P0010 will be reset to 0 on successful completion.
Ensure that enough space exists on the MMC card before transferring data (8kb).
P0803 Transfer data to
EEPROM
0 - 2 0 - - - U16 3
Transfers values from External to inverter when none 0. P0010 must be set to 30 for this to be possible.
See P0802 for parameter values.
Note: Parameter is automatically reset to 0 (default) after transfer.
P0010 will be reset to 0 on successful completion.
P0804 Select Clone file 0 - 99 0 - - - U16 3
Select clone file to up / down load.
if P0804 = 0 then file name is clone00.bin
if P0804 = 1 then file name is clone01.bin
etc.
P0806 BI: Inhibit panel access - 0 U, T - - U32 /
Bin
3
Binector input to lock control panel access through external client.
r0807.0 BO: Displays client
access
- - - - - U16 3
Binector output to display whether command and setpoint source is connected to an external client.
Bit Signal name 1 signal 0 signal
00 Master control active Yes No
P0809[0...2] Copy command data set
(CDS)
0 - 2 [0] 0 [1] 1
[2] 0
T - - U16 2
Calls 'Copy command data set (CDS)' function. The list of all command data sets (CDS) parameters is
shown in "Index" at the end of the manual.
Example: Copying of all values from CDS0 to CDS2 can be accomplished by the following procedure:
P0809[0] = 0 Copy from CDS0
P0809[1] = 2 Copy to CDS2
P0809[2] = 1 Start copy
Index: [0] Copy from CDS
[1] Copy to CDS
[2] Start copy
Note: Start value in index 2 is automatically reset to '0' after execution of function.
P0810 BI: command data set bit
0 (Hand / Auto)
- 0 U, T - - U32 /
Bin
2
Selects command source from which to read Bit 0 for selecting a command data set (CDS). The actual
selected CDS is displayed in r0054.15 (CDS bit 0) and r0055.15 (CDS bit 1). The actual active CDS is
displayed in r0050.
Note: P0811 is also relevant for command data set (CDS) selection.
